General
MT1.25
MT1.25
Click to enlarge the photo to see the full gallery.
XJ 25
Description
Modern elegant design
The elegant and compact form is optimal for small farms and use around the house.
Powerful hydraulic arm
The available hydraulic arm, attached to the chassis, can be quickly and easily removed.
HST hydrostatic
The dual pedal HST system increases ease of use when changing direction and speed.
Excellent Ground Clearance of the Mower
The mower, mounted in the middle, allows for easy attachment and removal and provides a ground clearance of 152 mm.
Easy Adjustment of Mowing Height
The adjustment of the mower's cutting height, which is centrally mounted, is as easy as turning a dial.
Lifting capacity 440 kg
With a lifting capacity of 440 kg, you can operate a wide range of machines.
Spacious level surface
The entire flat surface offers plenty of legroom and makes it easy to dismount from the tractor.
ROTATABLE SEAT GRAMMER ®
The seat from the renowned manufacturer GRAMMER with a high backrest ensures good support and comfort. When choosing the rear excavation bucket, the seat is rotatable.
Specifications
| Tires | Front | 18 x 8.5 – 10 |
|---|---|---|
| Rear | 26 x 12.00 – 12 | |
| Dimensions and weight | Total length, from the bumper to the end of the towing bars. (mm) | 2470 |
| Overall width with tires (depending on the model).(mm) | 1190 | |
| Wheelbase (mm) | 1425 | |
| Overall height, to the top of the rollover protective structure (mm) | 2218 | |
| Ground clearance (mm) | 430 | |
| Inner turning circle diameter (mm) | 2400 | |
| Maximum steering angle of the front wheels (°) | +/- 54,5 | |
| Total weight, without weights (kg) | 655 | |
| Engine | Type | 3-cylinder, direct injection, water cooling |
| Model | Yanmar 3TNV80F | |
| Emissions | STAGE V | |
| Engine power HP (kW) | 24.7 KM / 18.4 kW | |
| PTO power (HP) | 17,2 | |
| Rated speed (rpm) | 3000 | |
| Engine torque (Nm) | 69 | |
| Displacement (cc) | 1267 | |
| PTO | Type | Independent |
| Intermediate PTO (rpm) *optional | 2500 | |
| Rear (rpm) | 540 | |
| Lifting arms | Pump (l/min) | 17 |
| Category, three-point hitch | CAT I | |
| Lifting capacity of hitch (kg) | 450 | |
| Hydraulic valves | 4 (front) | |
| Gearbox | Fuel Tank Capacity (ℓ) | 25 |
| Transmission type (options) | Hydrostatic | |
| Number of gears | 2 stages | |
| Forward speed (km/h) | 0 – 13.3 |
* Note: The dimensions of the tractor may vary depending on the mounted tires. We reserve the right to errors in the technical data and are not responsible for them.
